Cortex-M0 LPC1100系列微控制器

NXP's LPC1100L is the lowest-priced 32-bit MCU solution in the market, bringing higher value and ease-of-use than existing 8-/16-bit microcontrollers through unprecedented performance, simplicity, low power, and more importantly, dramatic reductions in code size for all 8-/16-bit applications. The LPC1100L series offers a seamless entry point for any 8-/16-bit customers looking to start with the scalable ARM architecture throughout their entire range of product development. Built around the new Cortex-M0 architecture, the smallest, lowest-power, and most energy-efficient ARM core ever developed, these MCUs are ideally-equipped for use in battery-powered consumer devices, smart meters, motor control, and more. Note: The LPC1100L series (comprised of LPC11xx/x02 products) is differentiated from non-L LPC1100 products by its lower power consumption and easy-to-use Power Profiles. Please refer to the datasheet and user manual for detailed information.

LPC1100(LPC11XX)系列--NXP恩智浦半导体微控制器芯片

NXP LPC1100 系列是市场上最低价32位MCU解决方案,比现存的8/16位微控制器有更高的性价比,易用性更强。此系列产品性能优异,使用简单,功耗低,更重要的是大大简化了所有8/16位实际应用中的代码。LPC1100系列提供了一个无缝接入点,任何8/16位的用户都可以在整个产品开发过程中,使用ARM架构。基于Cortex-M0架构的LPC1100,体积达到最小,功耗最低,在电池供电设备、智能仪表、马达控制等应用中是最理想的解决方案。

Key Features:

  • ARM Cortex-M0 processor, 50MHz operation
  • Superior code density and higher performance than 8-/16-bit MCUs
  • Industry's lowest active power consumption with easy-to-use power profiles
  • Provides an easy migration path to Cortex-M3

主要特性:

  • ARM Cortex-M0 处理器,工作频率 50MHz
  • 比8/16位MCU有更好的代码密度,更高的性能
  • 带有更易使用的电源部件,具有工业级最低的功耗
  • 与Cortex-M3 结合便容易

LPC1100系列ARM选型表

Type number fmax [max] (MHz) FLASH (kB) RAM (kB) I/O pins USB device CAN UART I²C SPI ADC Timers PWM Package name PLL VDD [min] (V) VDD [max] (V) CPU supply voltage (V)
LPC1110FD20 4 1 16 1 1 1 5 SO20

LPC1111FDH20/002 8 2 16 1 1 1 5 TSSOP20
LPC1111FHN33/101 8 2 28 1 1 1 8 HVQFN33
LPC1111FHN33/102 8 2 28 1 1 1 8 HVQFN33
LPC1111FHN33/103 8 2 28 1 1 2 8 HVQFN33
LPC1111FHN33/201 8 4 28 1 1 1 8 HVQFN33
LPC1111FHN33/202 8 4 28 1 1 1 8 HVQFN33
LPC1111FHN33/203 8 4 28 1 1 2 8 HVQFN33

LPC1112FD20/102 16 4 16 1 1 1 5 SO20
LPC1112FDH20/102 16 4 14 1 - 1 5 TSSOP20
LPC1112FDH28/102 16 4 22 1 1 1 6 TSSOP28
LPC1112FHN24/202 16 4 19 1 1 1 6 HVQFN24
LPC1112FHN33/101 16 2 28 1 1 1 8 HVQFN33
LPC1112FHN33/102 16 2 28 1 1 1 8 HVQFN33
LPC1112FHN33/103 16 2 28 1 1 2 8 HVQFN33
LPC1112FHN33/201 16 4 28 1 1 1 8 HVQFN33
LPC1112FHN33/202 16 4 28 1 1 1 8 HVQFN33
LPC1112FHN33/203 16 4 28 1 1 2 8 HVQFN33
LPC1112FHI33/202 16 4 28 1 1 1 8 HVQFN33
LPC1112FHI33/203 16 4 28 1 1 2 8 HVQFN33

LPC1113FHN33/201 24 4 28 1 1 1 8 HVQFN33
LPC1113FHN33/202 24 4 28 1 1 1 8 HVQFN33
LPC1113FHN33/203 24 4 28 1 1 2 8 HVQFN33
LPC1113FHN33/301 24 8 28 1 1 1 8 HVQFN33
LPC1113FHN33/302 24 8 28 1 1 1 8 HVQFN33
LPC1113FHN33/303 24 8 28 1 1 2 8 HVQFN33
LPC1113FBD48/301 24 8 42 1 1 2 8 LQFP48
LPC1113FBD48/302 24 8 42 1 1 2 8 LQFP48
LPC1113FBD48/303 24 8 42 1 1 2 8 LQFP48

LPC1114FDH28/102 32 4 22 1 1 1 6 TSSOP28
LPC1114FN28/102 32 4 22 1 1 1 6 DIP28
LPC1114FHN33/201 32 4 28 1 1 1 8 HVQFN33
LPC1114FHN33/202 32 4 28 1 1 1 8 HVQFN33
LPC1114FHN33/203 32 4 28 1 1 2 8 HVQFN33
LPC1114FHN33/301 32 8 28 1 1 1 8 HVQFN33
LPC1114FHN33/302 32 8 28 1 1 1 8 HVQFN33
LPC1114FHN33/303 32 8 28 1 1 2 8 HVQFN33
LPC1114FHN33/333 56 8 28 1 1 2 8 HVQFN33
LPC1114FHI33/302 32 8 28 1 1 1 8 HVQFN33
LPC1114FHI33/303 32 8 28 1 1 2 8 HVQFN33
LPC1114FBD48/301 32 8 42 1 1 2 8 LQFP48
LPC1114FBD48/302 32 8 42 1 1 2 8 LQFP48
LPC1114FBD48/303 32 8 42 1 1 2 8 LQFP48
LPC1114FBD48/323 48 8 42 1 1 2 8 LQFP48
LPC1114FBD48/333 56 8 42 1 1 2 8 LQFP48
LPC1115FBD48/303 64 8 42 1 1 2 8 LQFP48

LPC11C12FBD48 50 16 8 40 1 1 1 2 8 5 13 LQFP48 Y 1.8 3.6 3.3
LPC11C14FBD48 50 32 8 40 1 1 1 2 8 5 13 LQFP48 Y 1.8 3.6 3.3
LPC11C22FBD48   16 8 36 1 1 1 2 8 4 LQFP48 Y 1.8 3.6
LPC11C24FBD48   32 8 36 1 1 1 2 8 4 LQFP48 Y 1.8 3.6

LPC11D14FBD100 5.00E+07 0 8 42 1 1 2 8 4 LQFP100 Y

LPC11U12FBD48 50  16 6 40 1 1 1 2 1 4 LQFP48 Y 1.8 3.6
LPC11U12FHN33 50  16 6 26 1 1 1 2 1 4 HVQFN32 Y 1.8 3.6
LPC11U13FBD48 50  24 6 40 1 1 1 2 1 4 LQFP48 Y 1.8 3.6
LPC11U14FBD48 50  32 6 40 1 1 1 2 1 4 LQFP48 Y 1.8 3.6
LPC11U14FET48 50  32 6 40 1 1 1 2 1 4 TFBGA48 Y 1.8 3.6
LPC11U14FHN33 50  32 6 26 1 1 1 2 8 4 HVQFN32 Y 1.8 3.6
LPC11U23FBD48 50 24 6 40 1   1 1 2   4   LQFP48 Y 1.8 3.6
LPC11U24FBD48 50 32 8 40 1   1 1 2   4   LQFP48 Y 1.8 3.6
LPC11U24FBD64 50 32 8 54 1   1 1 2   4   LQFP64 Y 1.8 3.6
LPC11U24FET48 50 32 6 40 1   1 1 2   4   TFBGA48 Y 1.8 3.6
LPC11U24FHI33 50 32 6 26 1   1 1 2   4   HVQFN32 Y 1.8 3.6
LPC11U24FHN33 50 32 8 26 1   1 1 2   4   HVQFN32 Y 1.8 3.6

LPC1000系列选型指南

Cortex_M0资料汇总

基于LPC1100的相关开发资料:

LPCXpresso环境下的LPC1100低功耗模式和唤醒时钟
